Configuration
7-286
SHB9300CRV EN 2.0
6. Change to the parameter level using PRG.
”Para” is displayed.
7. Select parameter 11.
8. Press SHIFT + PRG.
RDYisoff.BUSYisdisplayed.
All parameter sets are copied to the keypad. Copying is completed when BUSY is off (after
approx. one minute).
Stop!
Do not plug out the keypad before BUSY is off. Otherwise, TRIP ”PRX” will be indicated.
9. Enable the controller with X5/28 = HIGH.
10.Plug the keypad in controller 2.
11.Inhibit the controller 2 with X5/28 = LOW.
12.Use the arrow keys to change from the menus to the code level.
”Code” is displayed.
13.With z or y select C0002.
14.Change to the parameter level using PRG.
”Para” is displayed.
15.Select parameter 20 to copy all parameter sets from the keypad to the controller 2 and to
save them.
16.Press SHIFT + PRG.
RDYisoff.BUSYisdisplayed.
All parameter sets are copied to controller 2 and saved. Copying and saving is completed
when BUSY is off.
17.Enable the controller with X5/28 = HIGH.
Note!
It is also possible to copy single parameter sets from the keypad to the controller 2:
l
For this, use parameters 11, 12, 13, or 14 instead of parameter 20 to copy the parameter sets
1, 2, 3, or 4 to the the controller 2.15.
l
The copied parameter sets must be saved if the changes are to remain valid after mains
switch-off (see chapter 7.8.2.3).
