Lenze EVS9323-EK User Manual

Configuration
7-301
 SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
[C0540] Function 1 0{1}5Function of the encoder outputs
0 Analog input
1 PH diff input
2 RES+ int 0
3RES+ext0
4X10=X9
5X10=X8
[C0541] CFG: AN-IN 5001 MCTRL-NACT @ Selection list 1 Of the analog input of DFOUT
[C0542] CFG: DF-IN 1000 FIXEDPHI 0 @ Selection list 4 Configuration of the dig. frequency input
[C0544] CFG: SYN-RDY 1000 FIXED 0 @ Selection list 2 Synchronisation signal for the zero pulse
C0545 Phase offset 0 0 {1 inc} 65535
C0547 DIS: C0541 -199.99 {0.01 %} 199.99 Display of C0541
C0548 DIS: C0544 01Display of C0544
C0549 DIS: C0542 -32767 {1 rpm} 32767 Display of C0542
C1799 DFOUT f
max
(kHz) 1250 20 {1} 1250
DFRFG
C0430
5
TP5 delay
0.218 0.000 {0.001ms} 2.000 TP5 delay
C0750 Vp denom 16 1 / 2 / 4 / 8 / 16 / 32 / 64 / 128 / 256 / 512 / 1024 / 2048 /
4096 / 8192 / 16384
Vp denominator position (denominator of the position
controller gain)
1Vp=1
2Vp=1/2
4Vp=1/4
8Vp=1/8
16 Vp = 1/16
32 Vp = 1/32
64 Vp = 1/64
128 Vp = 1/128
256 Vp = 1/256
512 Vp = 1/512
1024 Vp = 1/1024
2048 Vp = 1/2048
4096 Vp = 1/4096
8192 Vp = 1/8192
16384 Vp = 1/16384
C0751 DFRFG1 Tir 1.000 0.000 {0.001s} 999.900 DFRFG1 Tir (acceleration time)
C0752 Max speed 3000 1 {1 rpm} 16000 max. speed; here: max. make-up speed
C0753 DFRFG1 QSP 0.000 0.000 {0.001s} 999.900 QSP-Tif, deceleration time when deceleration ramp is
activated
C0754 PH error 2
.
10
9
10 {1} 2
.
10
9
DFRFG1 contouring error
C0755 Syn window 100 0 {1 inc} 65535 Synchronization window
C0756 Offset 0 -1
.
10
9
{1 inc} /1
.
10
9
Offset
C0757 Function 0 0/1 0NoTPstart
1WithTPstart
[C0758] CFG: IN 1000 FIXEDPHI-0 @ Selection list 4 Configuration phase input
[C0759] CFG: QSP 1000 FIXED0 @ Selection list 2 Digital input (control QSP)
[C0760] CFG: STOP 1000 FIXED0 @ Selection list 2 Digital input (ramp function generator stop)
[C0761] CFG: RESET 1000 FIXED0 @ Selection list 2 Digital input (reset integrators)
C0764
1
2
3
DIS: C0759
DIS: C0760
DIS: C0761
Display of
C0759
C0760
C0761
C0765 DIS: C0758 -32767 {1 rpm} 32767 Display of C0758
C0766 Direction of rotation 1 1{1}31 Direction of rotation CW/CCW
2CWrotation
3 CCW rotation
DFSET
C0033 Gearbox denom 1 1 {1} 32767 Gearbox factor (denominator) for DFSET
C0252 phase offset 0 -245760000 {1 inc} 245760000 Phase offset for DFSET
Fixed phase offset for digital frequency configuration
l 1 rev. = 65536 inc
