Lenze EVS9323-EK User Manual

Configuration
7-302

SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
C0253 phase n-trim * -32767 {1 inc} 32767 speed-dependent phase trimming
Å depending on C0005, C0025, C0490
l Change of C0005, C0025, or C0490 resets C0253 to
the default setting
l 1 rev. = 65536 inc
l C0253 is reached at 15000 rpm
C0255 Threshold P03 327680 10 {1 inc} 1800000000 Contouring error limit for fault P03
l 1 rev. = 65536 inc
l Contouring error > C0255 sets trip ”P03”
C0430
1
2
3
4
TP1 delay
TP2 delay
TP3 delay
TP4 delay
0.218
0.218
0.218
0.218
0.000 {0.001 ms} 2.000 TP1 delay
[C0520] CFG: IN 1000 FIXEDPHI-0 @ Selection list 4 Configuration input
[C0521] CFG: VP-DIV 1000 FIXED 0 % @ Selection list 1 Configuration gain factor numerator
[C0522] CFG: RAT-DIV 1000 FIXED 0 % @ Selection list 1 Configuration gear factor numerator
[C0523] CFG: A-TRIM 1000 FIXED 0 % @ Selection list 1 Configuration phase trimming
[C0524] CFG: N-TRIM 1000 FIXED0 % @ Selection list 1 Speed trimming of DFSET
[C0525] CFG: 0-PULSE 1000 FIXED 0 @ Selection list 2 Configuration one-time zero pulse activation
[C0526] CFG: RESET 1000 FIXED0 @ Selection list 2 CFG: DFSET-RESET
Reset integrators
[C0527] CFG: SET 1000 FIXED0 @ Selection list 2 Configuration - set integrators
C0528
1
2
DIS: 0-pulse A
DIS: Offset
0 -2
.
10
9
{1} 2
.
10
9
Display parameter
Zero pulse phase difference
C0529 Multip offset 1 -20000 {1} 20000 Offset multiplier
C0530 DF evaluation 0 0{1}1Evaluation of the digital frequency
0withfactor
1nofactor
C0531 Act 0 div 1 1 {1} 16384 Actual zero pulse divider
C0532 0-pulse/TP 1 1{1}2Selection of zero pulse or touch probe
1 0-pulse
2 Touch probe
C0533 Vp denom 1 1 {1} 32767 Gain factor denominator
C0534 0 pulse fct 0 0 {1} 13 DFSET zero pulse function
0Inactive
1 Continuous
2 Cont. switch
10 Once,fast way
11 Once, CW
12 Once, CCW
13 Once,2*0-pulse
C0535 Set 0 div 1 1 {1} 16384 DFSET set zero pulse divider
C0536
1
2
3
DIS: VP-DIV
DIS: RAT-DIV
DIS: A-TRIM
-32767 {1} 32767 Absolute analog input signals
C0537 DIS: N-TRIM -199.99 {0.01 %} 199.99 Relative analog input signal
C0538
1
2
3
DIS: 0-PULSE
DIS: RESET
DIS: SET
digital input signals
C0539 DIS: IN -32767 {1 rpm} 32767 Input signal
C0546 Min inc/rev 1000 -245760000 {1inc} 245760000 Min. incr. per rev.
C1255 CFG: N-TRIM2 1000 @ Selection list 4 CFG: DFSET-N-TRIM2
C1258 DIS: C1255 0 -32767 {1 rpm} 32767 Display of C1255
DIGDEL
C0720 Function 2 0{1}2Selection of the function
0 On delay
1Offdelay
2 On/Off delay
