Configuration
7-303
 SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
C0721 Delay T 1.000 0.001 {0.001 s} 60.000 Delay time DIGDEL1
[C0723] CFG: IN 1000 FIXED 0
@
Selection list 2 Digital input of DIGDEL1
C0724 DIS: C0723 Display of C0723
C0725 Function 2 0{1}2Selection of the function
0 ON delay
1OFFdelay
2 ON/OFF delay
C0726 Delay T 1.000 0.001 {0.001 s} 60.000 Delay time DIGDEL2
[C0728] CFG: IN 1000 FIXED0
@
Selection list 2 Digital input
C0729 DIS: C0728 Display of C0728
DIGIN
C0114
1
2
3
4
5
DIGIN pol
DIGIN pol
DIGIN pol
DIGIN pol
DIGIN pol
0
0
0
1
0
0{1}1Terminal polarity
0:HIGH active; 1: LOW active
1X5/E1
2X5/E2
3X5/E3
4X5/E4
5X5/E5
C0443 DIS: DIGIN-OUT 0 {1} 255 Signals at X5/E1 to X5/E5, decimal value
l
Binary interpretation indicates terminal signals
DIGOUT
[C0117]
1
2
3
4
CFG: DIGOUT1
CFG: DIGOUT2
CFG: DIGOUT3
CFG: DIGOUT4
*
15000
10650
500
5003
@
Selection list 2
DCTRL-TRIP
CMP1-OUT
DCTRL-RDY
MCTRL-MMAX
Signal configuration DIGOUT
Ã…
depending on C0005
1X5/A1
2X5/A2
3X5/A3
4X5/A4
C0118
1
2
3
4
DIGOUT pol
DIGOUT pol
DIGOUT pol
DIGOUT pol
1
1
0
0
0{1}1Terminal polarity DIGOUT
0 High active
1 Low active
1: X5/A1, 2: X5/A2, 3: X5/A3, 4: X5/A4
C0444 DIS: C0118 01Display of C0118
DT
C0650 DT1-1 gain 1.00 -320.00 {0.01} 320.00 Gain of DT1-1 component
C0651 Delay T 1.00 0.005 {0.01 s} 5.000 Time constant of DT1-1
[C0652] CFG: IN 1000 FIXED 0 %
@
Selection list 1 Configuration analog input of DT1-1
C0653 Sensibility 1 1{1}7Input sensitivity of DT1-1
1 15-bit
2 14-bit
3 13-bit
4 12-bit
5 11-bit
6 10-bit
79-bit
C0654 DIS: IN -199.99 {0.01 %} 199.99 Analog input signal of DT1-1
FCNT
C1100 Function 1 1{1}21Return
2Hold
[C1101]
1
2
CFG: LD-VAL
CFG: CMP-VAL
1000 FIXED0%
@
Selection list 1 Configuration analog inputs
[C1102]
1
2
3
CFG: CLKUP
CFG: CLKDWN
CFG: LOAD
1000 FIXED0
@
Selection list 2 Digital inputs
C1103 DIS: C1101 -32768 {1} 32768 Display of C1101
C1104 DIS: C1102 Display of C1102
FDO
