Configuration
7-304

SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
[C0116]
1
...
32
CFG: FDO
...
CFG: FDO
1000 FIXED 0 @ Selection list 2 Signal configuration FDO
FDO0
...
FDO31
Free digital outputs can only be evaluated when networ-
ked with automation interfaces.
C0151 DIS: FDO (DW) Bit00 Bit00 {01} Bit 31 Display (hex.) of free digital outputs
l Binary interpretation indicates the bit states
FEVAN
C1090 Output signal -2147483648 {1} 2147483647 Output signal of FEVAN1
C1091 Code 141 2 {1} 2000 FEVAN1 Code
C1092 Subcode 0 0 {1} 255 FEVAN1 Subcode
C1093 Numerator 1.0000 0.0001 {0.0001} 100000.0000 FEVAN1 numerator
C1094 Denominator 0.0001 0.0001 {0.0001} 100000.0000 FEVAN1 denominator
C1095 Offset 0 0 {1} 1000000000 FEVAN1 Offset
[C1096] CFG: IN 1000 FIXED0% @ Selection list 1 Configuration analog input of FEVAN1
[C1097] CFG: LOAD 1000 FIXED0 @ Selection list 2 Digital inputs of FEVAN1
C1098 DIS: C1096 -32768 {1} 32767 Display of C1096
C1099 DIS: C1097 Display of C1097
C1500 Output signal -2147483648 {1} 2147483647 Output signal of FEVAN2
C1501 Code 141 2 {1} 2000 Target code of FEVAN2
C1502 Subcode 0 0 {1} 255 Target subcode FEVAN2
C1503 Numerator 1.0000 0.0001 {0.0001} 100000.0000 Numerator of FEVAN2
C1504 Denominator 0.0001 0.0001 {0.0001} 100000.0000 FEVAN2 denominator
C1505 Offset 0 0 {1} 1000000000 Offset of FEVAN2
[C1506] CFG: IN 1000 FIXED0% @ Selection list 1 Configuration analog input of FEVAN2
[C1507] CFG: LOAD 1000 FIXED0 @ Selection list 2 Digital inputs of FEVAN2
C1508 DIS: C1506 -32768 {1} 32767 Display of C1506
C1509 DIS: C1507 Display of C1507
FIXSET
C0560
1
2
3
4
5
..
15
Fixed setpoints
100
75
50
25
0
..
0
-199.99 {0.01 %} 199.99
[C0561] CFG: AIN 1000 FIXED0 % @ Selection list 1 Configuration analog input of FIXSET1
[C0562]
1
2
3
4
CFG: IN
CFG: IN
CFG: IN
CFG: IN
1000 FIXED 0 @ Selection list 2 Configuration of digital inputs
C0563 DIS: C0561 -199.99 {0.01 %} 199.99 Display of C0561
C0564 DIS: C0562 Display of C0562
FLIP
[C0770] CFG: D 1000 FIXED0 @ Selection list 2 Data input of FLIP1
[C0771] CFG: CLK 1000 FIXED0 @ Selection list 2 Configuration clock input of FLIP1
[C0772] CFG: CLR 1000 FIXED0 @ Selection list 2 Configuration reset input of FLIP1
C0773
1
2
3
DIS: C0770
DIS: C0771
DIS: C0772
Display of
C0770
C0771
C0772
[C0775] CFG: D 1000 FIXED0 @ Selection list 2 Data input of FLIP2
[C0776] CFG: CLK 1000 FIXED0 @ Selection list 2 Configuration clock input of FLIP2
[C0777] CFG: CLR 1000 FIXED0 @ Selection list 2 Configuration reset input of FLIP2
C0778
1
2
3
DIS: C0775
DIS: C0776
DIS: C0777
Display of
C0775
C0776
C0777
GEARCMP
C1260 Offset 0 -16383 {1} 16383 Offset
