Lenze EVS9323-EK User Manual

Configuration
7-307
 SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
10 DSKA56-140
11 DFKA71-120
12 DSKA71-140
13 DFKA80-60
14 DSKA80-70
15 DFKA80-120
16 DSKA80-140
17 DFKA90-60
18 DSKA90-80
19 DFKA90-120
20 DSKA90-140
21 DFKA100-60
22 DSKA100-80
23 DFKA100-120
24 DSKA100-140
25 DFKA112-60
26 DSKA112-85
27 DFKA112-120
28 DSKA112-140
MDSKAXX056-22, f
r
: 140Hz
MDFKAXX071-22, f
r
: 120Hz
MDSKAXX071-22, f
r
: 140Hz
MDFKAXX080-22, f
r
: 60Hz
MDSKAXX080-22, f
r
: 70Hz
MDFKAXX080-22, f
r
: 120Hz
MDSKAXX080-22, f
r
: 140Hz
MDFKAXX090-22, f
r
: 60Hz
MDSKAXX090-22, f
r
: 80Hz
MDFKAXX090-22, f
r
: 120Hz
MDSKAXX090-22, f
r
: 140Hz
MDFKAXX100-22, f
r
: 60Hz
MDSKAXX100-22, f
r
: 80Hz
MDFKAXX100-22, f
r
: 120Hz
MDSKAXX100-22, f
r
: 140Hz
MDFKAXX112-22, f
r
: 60Hz
MDSKAXX112-22, f
r
: 85Hz
MDFKAXX112-22, f
r
: 120Hz
MDSKAXX112-22, f
r
: 140Hz
Lenze asynchronous servo motors
without integrated temperature monitoring
l The temperature monitoring via resolver or encoder cable is automatically deactivated, i.e.:
C0583 = 3
C0584 = 3
C0594 = 3
50 DSVA56-140
51 DFVA71-120
52 DSVA71-140
53 DFVA80-60
54 DSVA80-70
55 DFVA80-120
56 DSVA80-140
57 DFVA90-60
58 DSVA90-80
59 DFVA90-120
60 DSVA90-140
61 DFVA100-60
62 DSVA100-80
63 DFVA100-120
64 DSVA100-140
65 DFVA112-60
66 DSVA112-85
67 DFVA112-120
68 DSVA112-140
DSVAXX056-22, f
r
: 140Hz
DFVAXX071-22, f
r
: 120Hz
DSVAXX071-22, f
r
: 140Hz
DFVAXX080-22, f
r
: 60Hz
DSVAXX080-22, f
r
: 70Hz
DFVAXX080-22, f
r
: 120Hz
DSVAXX080-22, f
r
: 140Hz
DFVAXX090-22, f
r
: 60Hz
DSVAXX090-22, f
r
: 80Hz
DFVAXX090-22, f
r
: 120Hz
DSVAXX090-22, f
r
: 140Hz
DFVAXX100-22, f
r
: 60Hz
DSVAXX100-22, f
r
: 80Hz
DFVAXX100-22, f
r
: 120Hz
DSVAXX100-22, f
r
: 140Hz
DFVAXX112-22, f
r
: 60Hz
DSVAXX112-22, f
r
: 85Hz
DFVAXX112-22, f
r
: 120Hz
DSVAXX112-22, f
r
: 140Hz
New generation of Lenze synchronous servo motors
integrated temperature monitoring via resolver or encoder cable
l The temperature monitoring via resolver or encoder cable is automatically activated, i.e.:
C0583 = 0
C0584 = 2
C0594 = 0
110 DSKS56-23-150
111 DSKS56-33-150
112 DSKS71-13-150
113 DFKS71-13-150
114 DSKS71-23-150
115 DFKS71-23-150
116 DSKS71-33-150
117 DFKS71-33-150
MDSKSXX056-23, f
r
: 150Hz
MDSKSXX056-33, f
r
: 150Hz
MDSKSXX071-13, f
r
: 150Hz
MDFKSXX071-13, f
r
: 150Hz
MDSKSXX071-23, f
r
: 150Hz
MDFKSXX071-23, f
r
: 150Hz
MDSKSXX071-33, f
r
: 150Hz
MDFKSXX071-33, f
r
: 150Hz
Lenze inverter motor in star connection
l The temperature monitoring via resolver or encoder cable is automatically deactivated, i.e.:
C0583 = 3
C0584 = 3
C0594 = 3
