Configuration
7-314

SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
C0738 Scanning period 3 3 {1} 21 Selection of the scanning period
31ms
42ms
55ms
610ms
720ms
850ms
9 100 ms
10 200 ms
11 500 ms
12 1 s
13 2 s
14 5 s
15 10 s
16 20 s
17 50 s
18 1 min
19 2 min
20 5 min
21 10 min
C0739 Number of channels 4 1{1}4Number of channels to be measured
C0740 Start 0 0 {1} 16383 Determine the start point for reading the data memory
Selection of a memory block
C0741
1
2
3
4
DIS: Version
DIS: Memory space
DIS: Data width
DIS: Number of
channels
1Version
2 Memory space
3Datawidth
4 Number of channels
C0744 Memory space 2048 0{1}6Adapt memory capacity to the measuring
task
0 512
1 1024
2 1536
3 2048
4 3072
5 4096
6 8192
C0749
1
2
3
DIS: Index cancel
DIS: Index trigger
DIS: Index end
Information about storing measured values
PCTRL
C0222 PCTRL Vp 1.0 0.1 {0.1} 500.0 Process controller gain V
p
C0223 PCTRL Tn 400 20 {1 ms} 99998 Process controller integral component T
n
99999 ms switched off
C0224 PCTRL Kd 0.0 0.0 {0.1} 5.0 Process controller differential component K
d
C0325 Vp2 adapt 1.0 0.1 {0.1} 500.0 Process controller adaptation gain (V
p2
)
C0326 Vp3 adapt 1.0 0.1 {0.1} 500.0 Process controller adaptation gain (V
p3
)
C0327 Set2 adapt 100.00 0.00 {0.01 %} 100.00 Set speed threshold of the process controller adaptation
Condition: C0327 > C0328
C0328 Set1 adapt 0.00 0.00 {0.01 %} 100.00 Set speed threshold of the process controller adaptation
Condition: C0328 < C0327
C0329 Adapt on/off 0 Activate process controller adaptation
0
:
N
o
p
r
o
c
e
s
s
c
o
n
t
r
o
l
l
e
r
a
d
a
p
t
a
t
i
o
n
C
0
3
2
9
A
d
a
p
t
o
n
/
o
f
f
0
0no
1ExternVp
2 Set-value
3Ctrldiff
A
c
t
i
v
a
t
e
p
r
o
c
e
s
s
c
o
n
t
r
o
l
l
e
r
a
d
a
p
t
a
t
i
o
n
0: No process controller adaptation
1: Externally via input
2: Adaptation via setpoint
3: Adaptation via control difference
C0332 PCTRL Tir 0.000 0.000 {0.001 s} 999.900 Process controller acceleration time T
ir
Ref. to setpoint change 0 ¡ 100 %
C0333 PCTRL Tif 0.000 0.000 {0.001 s} 999.900 Process controller deceleration time T
ir
Ref. to setpoint change 0 ¡ 100 %
C0336 DIS: act Vp 0.0 {0.1} 500.0 Process controller actual V
p
