Configuration
7-313
 SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
[C0832]
1
2
3
CFG: IN1
CFG: IN2
CFG: IN3
1000 FIXED0 @ Selection list 2 Digital inputs OR2
C0833 DIS: C0832 Display of C0832
[C0834]
1
2
3
CFG: IN1
CFG: IN2
CFG: IN3
1000 FIXED0 @ Selection list 2 Digital inputs of the OR element OR3
C0835 DIS: C0834 Display of C0834
[C0836]
1
2
3
CFG: IN1
CFG: IN2
CFG: IN3
1000 FIXED0 @ Selection list 2 Digital inputs of the OR element OR4
C0837 DIS: C0836 Display of C0836
[C0838]
1
2
3
CFG: IN1
CFG: IN2
CFG: IN
1000 FIXED0 @ Selection list 2 Digital inputs of the OR element OR5
C0839 DIS: C0838 Display of C0838
OSZ
2 Free/Inhibit 0 0{1}1For reading, the data memory must be ena-
bled
0 Read data inhibited
1 Read data enabled
C0730 Mode 0 0{1}1Start / stop of the measuring value recor-
ding
0 Start measurement
1 Stop measurement
C0731 Status 0{1}5Actual operating status
0 Measurement completed
1 Measurement active
2 Trigger detected
3Cancel
4 Cancel after trigger
5 Read memory
[C0732]
1
2
3
4
CFG: channel1
CFG: channel2
CFG: channel3
CFG: channel4
1000 FIXED0% @ Selection list 1 Configuration analog inputs
[C0733]
1
CFG: Dig. trigger
1000 FIXED0 @ Selection list 2 Configuration trigger input
C0734 Trigger source 0 0{1}4Selection of trigger source
0 dig. trigger input
1 Channel 1
2 Channel 2
3 Channel 3
4 Channel 4
C0735 Trigger level 0 -32767 {1} 32767 Adjust trigger level to channel 1 ... 4
C0736 Trigger signal 0 0{1}1Selection of trigger signal
0 LOW/HIGH edge
1 HIGH/LOW edge
C0737 Trigger delay 0.0 -100.0 {0.1 %} 999.99 Setting of pre and post-triggerung
