Troubleshooting and fault elimination
8-10

SHB9300CRV EN 2.0
8.4 Reset of fault messages
TRIP
l After eliminating the fault, the pulse inhibit is only reset after acknowledgement of TRIP.
l Acknowledge TRIP by:
– Global Drive Control: Click the buttung ”TRIP reset” in the dialog box ”Diagnostics 9300”.
( & 8-4, “Working with the history buffer”)
– Keypad 9371 BB:
Press STOP key. Then press RUN to enable the controller again.
– Fieldbus module: Set C0043 = 0
– Control word C0135
– Terminal X5/E5
– Control word AIF
– Control word system bus (CAN)
Note!
If a TRIP source is still active, TRIP cannot be reset.
Message
l After eliminating the fault, the pulse inhibit is reset automatically.
Warning!
After eliminating the fault, the drive starts automatically..
FAIL-QSP
l After eliminating the fault, the pulse inhibit is only reset after acknowledgement of TRIP.
l Acknowledge TRIP by:
– Global Drive Control: Click the buttung ”TRIP reset” in the dialog box ”Diagnostics 9300”.
( & 8-4, “Working with the history buffer”)
– Keypad 9371 BB:
Press STOP key. Then press RUN to enable the controller again.
– Fieldbus module: Set C0043 = 0
– Control word C0135
– Terminal X5/E5
– Control word AIF
– Control word system bus (CAN)
Note!
If a TRIP source is still active, TRIP cannot be reset.
Warning
l After having eliminated the fault, the warning is reset automatically.
