Troubleshooting and fault elimination
8-9
 SHB9300CRV EN 2.0
Display RemedyCauseFaultFault
No.
2)
Sd2 82 Resolver fa ult Resolver cable interrupted.
l
Check the resolver cable for open circuit
l
Check resolver.
l
or switch off monitoring (C0586 = 3).
Sd3 83 Encoder fault at X9/8
Cable interrupted. Check cable for open circuit.
Input X9 PIN 8 not assigned. Assign input X9 PIN 8 with 5V or switch off monitoring
(C0587 = 3).
Sd5 85 Master current source
defective
Master current at X6/1 X6/2 < 2mA.
l
Check cable for open circuit.
l
Check master current source.
Sd6 86 Sensor fault Encoder of the motor temperature detection at X7 or X8
indicates indefinite values.
Check supply cable for firm connection.
Switch off monitoring with C0594 = 3 if necessary.
Sd7 87 Encoder fault Absolute encoder with RS485 interface does not
transmit data.
Check supply cable.
Check encoder.
Check voltage supply C0421.
No Stegmann encoder connected.
1)
Temperature detection via resolver or incremental encoder.
2)
Displayed value = {fault no.} + 0 TRIP
= {fault no.} + 1000
Message
= {fault no.} + 2000
War n i n g
= {fault no.} + 2000
FAIL-QSP
