Application examples
15-5
 SHB9300CRV EN 2.0
15.3 Filling
D elivery pum p (cam drive)
Transport
Movement
Standstill
M achine cycle
Profile for a delivery drive (in principle)
F illin g
movement
Feed phase
+U GL1 L2 L3
X7
-U G U V W
X4
HI LO GND
X5
28 E1 E2 E3 E4 E5 39 A1 A2 A3 A4 59
93XX
X10
=
-
24V
M
RS
3
9
+
+/-10V
1
X6
2
Speed
setpoint
Selection of the configuration
l
C0005 = 13000 / 13300
Features
– Product-specific filling with minimum bubble generation
– Virtual master value
– Product changes at every clock pulse
– Option: switching point for handshake with conveyor belt
