Application examples
15-7
 SHB9300CRV EN 2.0
15.4 Mark-controlled cam profile start
C u tte r
C u tte r
M ark sensor
M aster value encoder
MovementMovement
M achine cycle
Profile for a cutting drive (in principle)
Stand-
s till
Sensor position
+U GL1 L2 L3
X7
-U G U V W
X4
HI LO GND
X5
28 E1 E2 E3 E4 E5 39 A1 A2 A3 A4 59
93XX
X9
=
- 24V
M
RS
3
9
+
Sensor
Selection of the configuration
l C0005 = 10800
Features
– Mark-controlled start for the correct position for the cut
– Offset selection for the fine adjustment of the position
– Easy changeover in the event of product changes
