Lenze EVS9323-EK User Manual

Installation
4-27
 SHB9300CRV EN 2.0
Features:
l CAN based with bus protocol according to CANopen (CAL-based Communication Profile
DS301)
l Bus expansion:
– 25 m at max. 1 Mbit/s baud rate
–upto1kmwithreducedbaudrate
l Extremely reliable data transmission (Hamming distance = 6)
l Signal level to ISO 11898
l Up to 63 bus devices are possible
l Access to all Lenze parameters
l Master functions integrated into the controller
– Data exchange possible between controllers without participation of a master system
(current ratio control, speed synchronization, etc.)
The following connections of the system bus connection are possible:
l Connection to a decentral terminal extension for digital and analog inputs and outputs
l Connection to a superimposed control (PLC, decentral digital inputs and outputs, keypad)
l Interconnection of several controllers
Automation interface (X1)
The automation interface (X1) is used for the connection of different plug-on modules
l Operating module
l Fieldbus modules
– RS232, RS485, optical fibre, type 2102 (LECOM-A/B/LI),
– INTERBUS, type 2111
– PROFIBUS, type 2131
