Data model evaluation
Data model
Relative model A profile consists of max. 5 sections with equidistant points. Linear interpolation between the points.
Absolute model A profile consists of arbitrarily distributed points. Linear interpolation between the points.
l
Depending on the data model selected and the number of profiles, different numbers of
points are available:
Data model Number of points available per profile
*)
Relative model 256
Absolute model 64
*) For the use of 8 different cam profiles
Note!
Please observe when distributing the points that at max. line speed a maximum of 2
points
/
ms
will
be exceeded.
l
The field “profile number” of the dialog “basic data” determines the number of profiles used.
It is possible to select between 1, 2, 4 and 8 different profiles. The number of points available
depends on the settings selected:
Number of profiles Number of points available per profile*
1 2048
2 1024
4 512
8 256
*For the relative data model
