Commissioning
5-14

SHB9300CRV EN 2.0
Cam data
Before commissioning, the cam data must be generated with Global Drive Control and then
transmitted to the drive. The following cam profiles are in factory setting. They are effective
independently of the basic parameter setting.
Profile 1 Electronic gear (linear position profile)
Profile 2 Forward / backward movement with a standstill in the intersection of the motion
Profile 3 Forward / backward movement with a standstill at the end of motion
Profile 4 Smooth feed
Profiles 5 - 8 No motion
Warning!
With factory setting, the motor must be off load, i.e. it must have a mechanical connection with the
machine.
5.9.2 Configuration C0005 = 10000 cam profiler (see chapter 15.1, (
&
15-1) )
5.9.3 Configuration C0005 = 11000 welding bar drive (see chapter 15.2, (
&
15-3) )
