Function block library
7-52

SHB9300CRV EN 2.0
Signal Source Note
Name Type DIS DIS format CFG List Lenze
CAN-CTRL.B0 d C0136/2 bin - - -
CAN-CTRL.B1 d C0136/2 bin - - -
CAN-CTRL.B2 d C0136/2 bin - - -
CAN-CTRL.B4 d C0136/2 bin - - -
CAN-CTRL.B5 d C0136/2 bin - - -
CAN-CTRL.B6 d C0136/2 bin - - -
CAN-CTRL.B7 d C0136/2 bin - - -
CAN-CTRL.B12 d C0136/2 bin - - -
CAN-CTRL.B13 d C0136/2 bin - - -
CAN-CTRL.B14 d C0136/2 bin - - -
CAN-CTRL.B15 d C0136/2 bin - - -
CAN-IN1.W1 a C0866/1 dec [%] - - - +16384 = +100 %
CAN-IN1.W2 a C0866/2 dec [%] - - - +16384 = +100 %
CAN-IN1.W3 a C0866/3 dec [%] - - - +16384 = +100 %
CAN-IN1.D1 ph C0867/1 dec [inc] - - - 65536 = 1 revolution
CAN-IN1.B0 d C0863/1 hex - - -
CAN-IN1.B1 d C0863/1 hex - - -
CAN-IN1.B2 d C0863/1 hex - - -
CAN-IN1.B3 d C0863/1 hex - - -
CAN-IN1.B4 d C0863/1 hex - - -
CAN-IN1.B5 d C0863/1 hex - - -
CAN-IN1.B6 d C0863/1 hex - - -
CAN-IN1.B7 d C0863/1 hex - - -
CAN-IN1.B8 d C0863/1 hex - - -
CAN-IN1.B9 d C0863/1 hex - - -
CAN-IN1.B10 d C0863/1 hex - - -
CAN-IN1.B11 d C0863/1 hex - - -
CAN-IN1.B12 d C0863/1 hex - - -
CAN-IN1.B13 d C0863/1 hex - - -
CAN-IN1.B14 d C0863/1 hex - - -
CAN-IN1.B15 d C0863/1 hex - - -
CAN-IN1.B16 d C0863/2 hex - - -
CAN-IN1.B17 d C0863/2 hex - - -
CAN-IN1.B18 d C0863/2 hex - - -
CAN-IN1.B19 d C0863/2 hex - - -
CAN-IN1.B20 d C0863/2 hex - - -
CAN-IN1.B21 d C0863/2 hex - - -
CAN-IN1.B22 d C0863/2 hex - - -
CAN-IN1.B23 d C0863/2 hex - - -
CAN-IN1.B24 d C0863/2 hex - - -
CAN-IN1.B25 d C0863/2 hex - - -
CAN-IN1.B26 d C0863/2 hex - - -
CAN-IN1.B27 d C0863/2 hex - - -
CAN-IN1.B28 d C0863/2 hex - - -
CAN-IN1.B29 d C0863/2 hex - - -
CAN-IN1.B30 d C0863/2 hex - - -
CAN-IN1.B31 d C0863/2 hex - - -
