Function block library
7-105
SHB9300CRV EN 2.0
7.6.30.4 TRIP SET
The drive is controlled to the status set under code C0581 and indicates EEr(external error).
l
Thisfunctioncanbecontrolledvia4inputs.
– Control word CAN-CTRL bit 10 from CAN-IN1
– Control word AIF-CTRL bit 10 from AIF-IN
– Control word C0135 bit 10
– Free input DCTRL-TRIP-SET
l
All inputs are OR linked.
l
C0136/1 indicates the control word C0135
