Lenze EVS9326-EK User Manual

Function block library
7-130

SHB9300CRV EN 2.0
Signal Source Note
Name Type DIS DIS format CFG List Lenze
FDO-0 d C0151 hex C0116/1 2 1000
FDO-1 d C0151 hex C0116/2 2 1000
FDO-2 d C0151 hex C0116/3 2 1000
FDO-3 d C0151 hex C0116/4 2 1000
FDO-4 d C0151 hex C0116/5 2 1000
FDO-5 d C0151 hex C0116/6 2 1000
FDO-6 d C0151 hex C0116/7 2 1000
FDO-7 d C0151 hex C0116/8 2 1000
FDO-8 d C0151 hex C0116/9 2 1000
FDO-9 d C0151 hex C0116/10 2 1000
FDO-10 d C0151 hex C0116/11 2 1000
FDO-11 d C0151 hex C0116/12 2 1000
FDO-12 d C0151 hex C0116/13 2 1000
FDO-13 d C0151 hex C0116/14 2 1000
FDO-14 d C0151 hex C0116/15 2 1000
FDO-15 d C0151 hex C0116/16 2 1000
FDO-16 d C0151 hex C0116/17 2 1000
FDO-17 d C0151 hex C0116/18 2 1000
FDO-18 d C0151 hex C0116/19 2 1000
FDO-19 d C0151 hex C0116/20 2 1000
FDO-20 d C0151 hex C0116/21 2 1000
FDO-21 d C0151 hex C0116/22 2 1000
FDO-22 d C0151 hex C0116/23 2 1000
FDO-23 d C0151 hex C0116/24 2 1000
FDO-24 d C0151 hex C0116/25 2 1000
FDO-25 d C0151 hex C0116/26 2 1000
FDO-26 d C0151 hex C0116/27 2 1000
FDO-27 d C0151 hex C0116/28 2 1000
FDO-28 d C0151 hex C0116/29 2 1000
FDO-29 d C0151 hex C0116/30 2 1000
FDO-30 d C0151 hex C0116/31 2 1000
FDO-31 d C0151 hex C0116/32 2 1000
Function
You can freely select a digital signal source for every signal input.
l The corresponding bit in the data word (DWORD)is marked with FDO-x (e.g. FDO-0 for the
LSB and FDO-31 for the MSB).
l The DWORD is transferred to code C0151 and to the function blocks AIF-OUT, CAN-OUT1,
CAN-OUT2, and CAN-OUT3.
