Function block library
7-133
SHB9300CRV EN 2.0
Conversion
In the example, the conversion is performed at FB FEVAN1.
l
Thedataformatofthetargetcodeisimportantfortheconversion(seeattributetable,chapter
7.12).
l
Adapt input signal to the data format of the target code:
– C1093 (numerator)
– C1094 (denominator).
l
C1094 also fixes the decimal code of the target code:
– Set C1094 corresponding to the existing decimal codes of the target code. The number of
decimal codes can be obtained from the code table.
– 0.0001
no decimal codes
– 0.001
one decimal code
–0.01
decimal codes
–0.1
three decimal codes
–1
four decimal codes
l
For target codes with percentage standardization, the formula for the conversion must include
a scaling factor (see example 1).
