Lenze EVS9326-EK

Configuration
7-281

SHB9300CRV EN 2.0
Segments and status messages of the LCD display:
Segment Explanation
Code number Four-digit code number
Subcode number Two-digit subcode number
Parameter Parameter value with up to twelve digits
Te xt Text with max. 13 characters;
Operating level: Status information from C0183 or content of C0004
SH PRG p
SH PRG p : Parameter acceptance by pressing SHIFT + PRG (OFFLINE)
S
H
P
R
G
SH PRG: Parameter acceptance with SHIFT + PRG when the controller is inhibited (OFFLINE)
p : Parameter is directly accepted by the controller (ONLINE)
Empty: Parameter cannot be changed
Active level Menu = Menu level, Code = Code level, Para = Parameter level, Nothing displayed = Operating level
Status messages of the keypad
Display on off
RDY Ready for operation Initialization or fault
IMP Power outputs inhibited Power outputs enabled
FAIL Active fault No fault
I
MAX
Motor current setpoint

C0022 Motor current setpoint C0022
M
MAX
Speed controller 1 within limitation.
Drive is torque controlled.
Drive is speed controlled.
Key functions
”SHIFT + ” means:
1. Press SHIFT and remain pressing it.
2. Press another key indicated.
Keys
Function
K
e
y
s
Menu level Code level Parameter level/operating level
PRG - Change between code, parameter and operating level
SHIFT + PRG - - Parameter acceptance (depends on parameter
and menu)
z Next higher menu point Next higher code number Increase indicated number
SHIFT + z Quickly to next higher menu point Quickly increase code number Quickly increase displayed number
y Next lower menu point Next lower code number Decrease displayed number
SHIFT + y Quickly to next lower menu point Quickly decrease code number Quickly decrease displayed number
Y Next higher menu level Jump to menu level Cursor left
Z Next lower menu level (submenus)or code
level
- Cursor right
RUN Void STOP-key function
STOP Inhibit controller: Quick stop, ctrl. inhibit or switched off C0469
Trip reset: if a TRIPoccurs and the STOP key is pressed (independently of C0469)
Press RUN afterwards.
The LED in the STOP-key indicates its status.
l LED on: STOP-key pressed
l LED off: RUN-key pressed
