Lenze EVS9326-EK User Manual

Configuration
7-315
 SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
C0337 Bi/unipolar 0 0 bipolar
1 unipolar
Process controller range bipolar/unipolar
[C0800] CFG: SET 1000 FIXED0% @ Selection list 1 Configuration setpoint input
[C0801] CFG: ACT 1000 FIXED0% @ Selection list 1 Configuration actual value input
[C0802] CFG: INFLU 1000 FIXED0% @ Selection list 1 Configuration evaluation input
[C0803] CFG: ADAPT 1000 FIXED0% @ Selection list 1 Configuration adaptation input
[C0804] CFG: INACT 1000 FIXED0 @ Selection list 2 Configuration inactivation input
[C0805] CFG: I-OFF 1000 FIXED0 @ Selection list 2 Digital input (switch-off I component)
C0808
1
2
3
4
DIS: C0800
DIS: C0801
DIS: C0802
DIS: C0803
-199.99 {0.01 %} 199.99 Display of
C0800
C0801
C0802
C0803
C809
1
2
DIS: C0804
DIS: C0805
Display of
C0804
C0805
PHADD
[C1200]
1
2
3
CFG: IN
CFG: IN
CFG: IN
1000 FIXED0INC @ Selection list 3 Configuration input of PHADD1
C1201 DIS: C1200 -2147483647 {1} 2147483647 Display of C1200
PHCMP
C0695 Function 2 1{1}2Function comparator for phase signals PHCMP1
Compares the inputs IN1 and IN2
1IN1<IN2
2 |IN1| < |IN2|
[C0697]
1
2
CFG: IN
CFG: IN
1000 FIXED 0INC @ Selection list 3 Configuration phase inputs of PHCMP1
C0698 DIS: C0697 -2147483647 {1} 2147483647 Display of C0697
[C1205]
1
2
CFG: IN1
CFG: IN2
1000 FIXED0INC @ Selection list 3 Configuration inputs of PHCMP2
C1206 DIS: C1205 -2147483647 {1} 2147483647 Display of C1205
C1207 Function PHCMP2 2 1{1}2Function of PHCMP2
1 IN1 < IN2
2 |IN1| < |IN2|
[C1270]
1
2
CFG: IN
CFG: IN
1000 FIXED0INC @ Selection list 3 Configuration inputs of PHCMP3
C1271 DIS: C1270 -2147483647 {1} 2147483647 Display of C1270
C1272 Function PHCMP3 2 1{1}21 IN1 < IN2
2
 IN1  <  IN2 
PHDIFF
[C1230]
1
2
CFG: EN
CFG: RESET
1000 FIXED0 @ Selection list 2 Digital inputs of PHDIFF1
[C1231] CFG: IN 1000 FIXEDPHI-0 @ Selection list 4 Configuration inputs of PHDIFF1
[C1232]
1
2
CFG: SET
CFG: ADD
1000 FIXED0INC @ Selection list 3 Configuration inputs of PHDIFF1
C1235 DIS: C1230 Display of C1230
C1236 DIS: C1231 -32767 {1} 32767 Display of C1231
C1237 DIS: C1232 -2147483647 {1} 2147483647 Display of C1232
PHDIV
C0995 Factor 0 -31 {1} 31
[C0996] CFG: IN 1000 FIXED0INC @ Selection list 3 Configuration input phase division PHDIV1
C0997 DIS: C0996 -2147483647 {1} 2147483647 Display of C0996
PHINT
[C0990] CFG: IN 1000 FIXEDPHI0 @ Selection list 4 Input phase integrator PHINT1
[C0991] CFG: RESET 1000 FIXED0 @ Selection list 2 Reset input of PHINT1
C0992 DIS: C0990 -32767 {1} 32767 Display of C0990
