Commissioning
5-5
SHB9300CRV EN 2.0
5.5 Parameter set generation
Warning!
Do not change any controller settings not mentioned in this chapter.
Proceed systematically when generating a parameter set:
1. Select the basic configuration (use basic configuration 10000).
2. Adapt controller to mains conditions.
3. Adapt controller to motor.
4. Enter machine parameters.
5.5.1 Adapt the controller to the mains
4
3
2
1
5
grundein
Fig. 5-2 ”Basic settings” dialog box
Field
Command Function
1 Click field Selection of the configuration “10000”; cam
2 Click field Select values for the actual mains and operating conditions.
