Lenze GSS Series User Manual

Product description
Nameplate
3
19
Lenze • BA 12.0023 • 9.0
Pos. Contents
1 Manufacturer / production location
2 Type of motor / standard
3 Gearbox type
4 Motor type
5
Technical data
5.1 Ratio
5.2 Rated torque
5.3 Rated speed
5.4 Rated f requency
5.10 Number of poles
6 Mounting position / position of the system blocks
7
Lubricant details
7.1 Lubricant amount
7.2 Lubricant type
8
Brake data
8.1 Type
8.2 AC/DC brake voltage
8.3 Braking torque, electrical power input
9 Forfeedback/pulseencoderorresolverdata, 22
10
Production data
10.1 Order number
10.2 Material number
10.3 Serial number
11 Bar code
12 Motor number
13 Information with regard to the operating mode
14
Additional motor specifications
14.1 Temperature class
14.2 Enclosure
14.3 Motor protection
15 Applicable conformities, approvals and certificates
16
Rated data for various frequencies
16.1 Hz = frequency
16.2 kW = motor power
16.3 rpm = motor speed
16.4 V = motor voltage
16.5 A = motor current
16.6 cos  = motor power factor
16.7  = motor efficiency: at a rated power of 100%
16.8  = motor efficiency: at a rated power of 75%
16.9  = motor efficiency: at a rated power of 50%
17 Application factor (specified if <1.0) / load capacity
18 Year of manufacture / week of manufacture
19 UL file number
20
Customer data
20.1 Additional customer data
20.2 Customer order number
21 UL category (e.g. inverter duty motor)
22 C86 = motor code for controller parameterisation (code 0086)
23 Efficiency class
24 Partial load efficiencies for 50Hz operation at a rated power of 50% and 75%
26 CC number Department of Energy (optional)
27 Permissible ambient temperature (e.g. Ta  40°C)
29 Standstill current (ampere locked rotor ALR)
31 Plug design (number of poles)
