Lenze GSS Series - Attachment of gearboxes with hollow shafts and keyway

Mechanical installation
Mounting
Attachment of gearboxes with hollow shafts and keyway
5
34
Lenze • BA 12.0023 • 9.0
K12.0611
Auxiliary tool (recommended dimensions)
 d
H7
d
2
c
7
18
20
M6 4
25
30
M10
5
6
35 M12 7
40
45
M16 8
9
50
55
M16
M20
10
11
60
70
M20 13
14
80 M20 16
100 M24 24
Tab. 4 Dimensions in mm
 Note!
With the bevel gearbox, the hollow shafts are turned free in the middle
of the hollow shaft, i.e. the bore diameter is 0.1 mm higher here! A
sufficient length of the machine shaft must be observed.
GKR size l
1
min lmax.
03 85 100
04 105 120
05 127 143
06 150 170
Tab. 5 Dimensions in mm
