Mechanical installation
Mounting
Breather position, oil filling screw and drain plug
5
51
Lenze • BA 12.0023 • 9.0
Helical-bevel gearbox GKL07...09-3
A B
C D
E F
GT-GNG-GKL-001.iso/dms
A...F Mounting positions Breathing / oil filler plug
*
On both sides Oil drain plug
**
On the opposite side Oil-control plug
Pos. 1 or 2 Depending on version
Sealing plug without function
