Lenze I51AE175B - Page 4

6 Diagnoscs and fault eliminaon 67
6.1 LED status display 67
6.2 Diagnoscs parameter 68
6.2.1 Logbook 69
6.2.2 Error history buer 70
6.2.3 Inverter diagnoscs 73
6.2.4 Network diagnoscs 77
6.2.4.1 CANopen diagnoscs 78
6.2.4.2 Modbus diagnoscs 80
6.2.5 Diagnoscs of the inputs and outputs 81
6.2.5.1 Digital inputs and outputs 81
6.2.5.2 Analog inputs and outputs 82
6.2.6 Wireless-LAN diagnoscs 83
6.2.7 Setpoint diagnosc 84
6.2.8 Process controller status 85
6.2.9 Sequencer diagnoscs 85
6.2.10 Device idencaon 86
6.2.11 Device overload monitoring (i*t) 88
6.2.12 Heatsink Temperature Monitoring 88
6.2.13 Life-diagnosis 89
6.3 Error handling 90
6.3.1 Error types 90
6.3.2 Error conguraon 91
6.3.3 Error reset 91
6.3.4 Keypad error messages 91
6.4 Data handling 92
7 Basic seng 94
7.1 Mains voltage 95
7.2 Control source selecon 97
7.3 Selecon of setpoint source 98
7.3.1 Keypad setpoint default seng 101
7.4 Starng/stopping performance 103
7.4.1 Starng performance 103
7.4.2 Stopping performance 105
7.5 Frequency limits and ramp mes 106
7.6 Quick stop 109
7.7 S-shaped ramps 111
7.8 Opcal device idencaon 112
Contents
4
