Display code Short designaon Default seng Seng range Address Category
P333.xx V/f Imax contr.
└ P333.01 Gain 0.284 Hz/A * 0.000 ... 1000.000 Hz/A 0x2B08:001 MCTRL
└ P333.02 Reset me 2.3 ms * 1.0 ... 2000.0 ms 0x2B08:002 MCTRL
P334.xx Current contr.
└ P334.01 Gain 42.55 V/A * 0.00 ... 750.00 V/A 0x2942:001 MCTRL
└ P334.02 Reset me 4.50 ms * 0.01 ... 2000.00 ms 0x2942:002 MCTRL
P335.xx Moment of inert.
└ P335.01 Motor inera 3.70 kg cm² * 0.00 ... 20000000.00 kg cm² 0x2910:001 MCTRL
└ P335.02 Load inera 3.70 kg cm² * 0.00 ... 20000000.00 kg cm² 0x2910:002 MCTRL
└ P336.02 Ramp me 1.0 s 0.0 ... 60.0 s 0x2948:002 general
P337.xx
└ P337.01 Pos. torqlim src Max torque [0] Selecon list 0x2949:001 general
└ P337.02 Neg. torqlim src (-) Max torque [0] Selecon list 0x2949:002 general
└ P337.03 Act postorqlim x.x % - (Read only) 0x2949:003 general
└ P337.04 Act negtorqlim x.x % - (Read only) 0x2949:004 general
P340.xx Speed limitaon
└ P340.01 Upper limit 0 vel. unit -480000 ... 480000 vel. unit 0x2946:001 general
└ P340.02 Lower limit 0 vel. unit -480000 ... 480000 vel. unit 0x2946:002 general
└ P340.03 Uppspeed lim src Max. frequency [0] Selecon list 0x2946:003 general
└ P340.04 Lowspeed lim src (-) Max. freq. [0] Selecon list 0x2946:004 general
└ P340.05 Upper freq.limit Device for 50-Hz mains:
50.0 Hz
Device for 60-Hz mains:
60.0 Hz
-1000.0 ... 1000.0 Hz 0x2946:005 general
└ P340.06 Lower freq.limit Device for 50-Hz mains:
-50.0 Hz
Device for 60-Hz mains:
-60.0 Hz
-1000.0 ... 1000.0 Hz 0x2946:006 general
└ P340.07 Act uppspeed lim x.x Hz - (Read only) 0x2946:007 general
└ P340.08 Act lowspeed lim x.x Hz - (Read only) 0x2946:008 general
P350.xx Overspeed monit.
└ P350.01 Threshold 8000 rpm 50 ... 50000 rpm 0x2D44:001 general
└ P350.02 Response Fault [3] Selecon list 0x2D44:002 general
P351.xx ASM motor par.
└ P351.01 Rotor resistance 8.8944 Ω * 0.0000 ... 200.0000 Ω 0x2C02:001 MCTRL
└ P351.02 Mutual induct. 381.9 mH * 0.0 ... 50000.0 mH 0x2C02:002 MCTRL
└ P351.03 Magn. current 0.96 A * 0.00 ... 500.00 A 0x2C02:003 MCTRL
└ P351.04 Slip frequency x.x Hz - (Read only) 0x2C02:004 general
P352.xx PSM motor par.
└ P352.01 BEMF constant 41.8 V/1000rpm 0.0 ... 100000.0 V/1000rpm 0x2C03:001 MCTRL
P353.xx Overcurr. monit.
└ P353.01 Threshold 6.8 A * 0.0 ... 1000.0 A 0x2D46:001 general
└ P353.02 Response Fault [3] Selecon list 0x2D46:002 general
P354.00 Voltage reserve 5 % 1 ... 20 % 0x29E4 general
P400.xx Funcon list
└ P400.01 Enable inverter TRUE [1] Selecon list 0x2631:001 general
└ P400.02 Run Digital input 1 [11] Selecon list 0x2631:002 general
└ P400.03 Quick stop Not connected [0] Selecon list 0x2631:003 general
└ P400.04 Reset fault Digital input 2 [12] Selecon list 0x2631:004 general
└ P400.05 DC braking Not connected [0] Selecon list 0x2631:005 general
└ P400.06 Start forward Not connected [0] Selecon list 0x2631:006 general
└ P400.07 Start reverse Not connected [0] Selecon list 0x2631:007 general
└ P400.08 Run forward Not connected [0] Selecon list 0x2631:008 general
└ P400.09 Run reverse Not connected [0] Selecon list 0x2631:009 general
└ P400.10 Jog foward Not connected [0] Selecon list 0x2631:010 general
* Default seng depending on the size. Firmware version 05.00.00.00
Commissioning
Keypad parameter list
