Display code Short designaon Default seng Seng range Address Category
└ P414.01 Frequency 0.0 Hz 0.0 ... 599.0 Hz 0x4004:001 general
└ P414.02 PID value 0.00 PID unit -300.00 ... 300.00 PID unit 0x4004:002 general
└ P414.03 Torque 0.0 % 0.0 ... 1000.0 % 0x4004:003 general
P420.xx Dig.out.funcon
└ P420.01 Relay funcon Rdy for operat. [51] Selecon list 0x2634:001 general
└ P420.02 DO1 funcon Release brake [115] Selecon list 0x2634:002 general
└ P420.10 NetWordOUT1.00 Rdy for operat. [51] Selecon list 0x2634:010 general
└ P420.11 NetWordOUT1.01 Not connected [0] Selecon list 0x2634:011 general
└ P420.12 NetWordOUT1.02 Operat. enabled [52] Selecon list 0x2634:012 general
└ P420.13 NetWordOUT1.03 Error [56] Selecon list 0x2634:013 general
└ P420.14 NetWordOUT1.04 Not connected [0] Selecon list 0x2634:014 general
└ P420.15 NetWordOUT1.05 Quick stop [54] Selecon list 0x2634:015 general
└ P420.16 NetWordOUT1.06 Running [50] Selecon list 0x2634:016 general
└ P420.17 NetWordOUT1.07 Device warning [58] Selecon list 0x2634:017 general
└ P420.18 NetWordOUT1.08 Not connected [0] Selecon list 0x2634:018 general
└ P420.19 NetWordOUT1.09 Not connected [0] Selecon list 0x2634:019 general
└ P420.20 NetWordOUT1.10 Speed - setp=act [72] Selecon list 0x2634:020 general
└ P420.21 NetWordOUT1.11 At current limit [78] Selecon list 0x2634:021 general
└ P420.22 NetWordOUT1.12 Actual speed=0 [71] Selecon list 0x2634:022 general
└ P420.23 NetWordOUT1.13 Rot.dir.reversed [69] Selecon list 0x2634:023 general
└ P420.24 NetWordOUT1.14 Release brake [115] Selecon list 0x2634:024 general
└ P420.25 NetWordOUT1.15 Safe Torque O [55] Selecon list 0x2634:025 general
P421.xx DO inversion
└ P421.01 Relay inverted Not inverted [0] Selecon list 0x2635:001 general
└ P421.02 DO1 inversion Not inverted [0] Selecon list 0x2635:002 general
P430.xx Analog input 1
└ P430.01 AI1 input range 0 ... 10 VDC [0] Selecon list 0x2636:001 general
└ P430.02 AI1 freq @ min 0.0 Hz -1000.0 ... 1000.0 Hz 0x2636:002 general
└ P430.03 AI1 freq @ max Device for 50-Hz mains:
50.0 Hz
Device for 60-Hz mains:
60.0 Hz
-1000.0 ... 1000.0 Hz 0x2636:003 general
└ P430.04 AI1 PID @ min 0.00 PID unit -300.00 ... 300.00 PID unit 0x2636:004 general
└ P430.05 AI1 PID @ max 100.00 PID unit -300.00 ... 300.00 PID unit 0x2636:005 general
└ P430.06 AI1 lter me 10 ms 0 ... 10000 ms 0x2636:006 general
└ P430.07 AI1 dead band 0.0 % 0.0 ... 100.0 % 0x2636:007 general
└ P430.08 AI1 monit.level 0.0 % -100.0 ... 100.0 % 0x2636:008 general
└ P430.09 AI1 monit.cond. IN < threshold [0] Selecon list 0x2636:009 general
└ P430.10 AI1 error resp. Fault [3] Selecon list 0x2636:010 general
└ P430.11 Min. torque 0.0 % -400.0 ... 400.0 % 0x2636:011 general
└ P430.12 Max. torque 100.0 % -400.0 ... 400.0 % 0x2636:012 general
P431.xx Analog input 2
└ P431.01 AI2 input range 0 ... 10 VDC [0] Selecon list 0x2637:001 general
└ P431.02 AI2 freq @ min 0.0 Hz -1000.0 ... 1000.0 Hz 0x2637:002 general
└ P431.03 AI2 freq @ max Device for 50-Hz mains:
50.0 Hz
Device for 60-Hz mains:
60.0 Hz
-1000.0 ... 1000.0 Hz 0x2637:003 general
└ P431.04 AI2 PID @ min 0.00 PID unit -300.00 ... 300.00 PID unit 0x2637:004 general
└ P431.05 AI2 PID @ max 100.00 PID unit -300.00 ... 300.00 PID unit 0x2637:005 general
└ P431.06 AI2 lter me 10 ms 0 ... 10000 ms 0x2637:006 general
└ P431.07 AI2 dead band 0.0 % 0.0 ... 100.0 % 0x2637:007 general
└ P431.08 AI2 monit.level 0.0 % -100.0 ... 100.0 % 0x2637:008 general
└ P431.09 AI2 error resp. IN < threshold [0] Selecon list 0x2637:009 general
└ P431.10 AI2 error resp. Fault [3] Selecon list 0x2637:010 general
* Default seng depending on the size. Firmware version 05.00.00.00
