Display code Short designaon Default seng Seng range Address Category
└ P593.08 Frequency 0.02Hz Hz - (Read only) 0x400C:008 general
└ P593.09 Freq. [+/-16384] - - (Read only) 0x400C:009 general
P595.xx PAM monitoring
└ P595.02 Keep alive reg. 0 0 ... 65535 0x2552:002 general
└ P595.03 Time-out me 10.0 s 0.0 ... 6553.5 s 0x2552:003 general
└ P595.04 Reacon No response [0] Selecon list 0x2552:004 general
└ P595.05 Acon No acon [0] Selecon list 0x2552:005 general
└ P595.06 PAM status - - (Read only) 0x2552:006 general
└ P595.07 WLAN reset t.out 0 s 0 ... 65535 s 0x2552:007 general
P600.xx PID setup
└ P600.01 Operang mode Inhibited [0] Selecon list 0x4020:001 general
└ P600.02 PID process var. Analog input 1 [1] Selecon list 0x4020:002 general
└ P600.03 PID speed range 100 % 0 ... 100 % 0x4020:003 general
└ P600.04 PID line speed w/o speed.add. [0] Selecon list 0x4020:004 general
└ P600.05 Min speed lim -100.0 % -100.0 ... 100.0 % 0x4020:005 general
└ P600.06 Max speed lim 100.0 % -100.0 ... 100.0 % 0x4020:006 general
P601.00 PID P-component 5.0 % 0.0 ... 1000.0 % 0x4048 general
P602.00 PID I- component 400 ms 10 ... 6000 ms 0x4049 general
P603.00 PID D-component 0.0 s 0.0 ... 20.0 s 0x404A general
P604.00 PID setp.ramp 20.0 s 0.0 ... 100.0 s 0x404B general
P605.xx PID setp. limit
└ P605.01 Minimum setpoint -300.00 PID unit -300.00 ... 300.00 PID unit 0x404E:001 general
└ P605.02 Maximum setpoint 300.00 PID unit -300.00 ... 300.00 PID unit 0x404E:002 general
P606.xx PID speed op.
└ P606.01 Accel. me 1.0 s 0.0 ... 3600.0 s 0x4021:001 general
└ P606.02 Decel. me 1.0 s 0.0 ... 3600.0 s 0x4021:002 general
P607.xx PID inuence
└ P607.01 Acvaon me 5.0 s 0.0 ... 999.9 s 0x404C:001 general
└ P607.02 Mask out me 5.0 s 0.0 ... 999.9 s 0x404C:002 general
P608.xx PID alarms
└ P608.01 MIN alarm thrsh. 0.00 PID unit -300.00 ... 300.00 PID unit 0x404D:001 general
└ P608.02 MAX alarm thrsh. 100.00 PID unit -300.00 ... 300.00 PID unit 0x404D:002 general
└ P608.03 Bandw. feedback 2.00 % 0.00 ... 100.00 % 0x404D:003 general
P610.xx PID sleep mode
└ P610.01 Acvaon Disabled [0] Selecon list 0x4023:001 general
└ P610.02 Stop method Coasng [0] Selecon list 0x4023:002 general
└ P610.03 Freq. thresh. 0.0 Hz 0.0 ... 599.0 Hz 0x4023:003 general
└ P610.04 Feedback thresh. 0.00 PID unit -300.00 ... 300.00 PID unit 0x4023:004 general
└ P610.05 Delay me 0.0 s 0.0 ... 300.0 s 0x4023:005 general
└ P610.06 Recovery Setp. > P610.3 [0] Selecon list 0x4023:006 general
└ P610.07 Bandwidth 0.00 PID unit 0.00 ... 300.00 PID unit 0x4023:007 general
└ P610.08 Recovery thresh. 0.00 PID unit -300.00 ... 300.00 PID unit 0x4023:008 general
P615.xx Auto-rinsing
└ P615.01 Rinsing in idle Inhibited [0] Selecon list 0x4024:001 general
└ P615.02 Rinse interval 30.0 min 0.0 ... 6000.0 min 0x4024:002 general
└ P615.03 Rinse speed 0.0 Hz -599.0 ... 599.0 Hz 0x4024:003 general
└ P615.04 Rinse period 0.0 s 0.0 ... 6000.0 s 0x4024:004 general
P700.xx Device commands
└ P700.01 Load def. se. O / ready [0] Selecon list 0x2022:001 general
└ P700.03 Save user data O / ready [0] Selecon list 0x2022:003 general
└ P700.04 Load user data O / ready [0] Selecon list 0x2022:004 general
└ P700.05 Load OEM data O / ready [0] Selecon list 0x2022:005 general
└ P700.06 Save OEM data O / ready [0] Selecon list 0x2022:006 general
└ P700.07 Load par. set 1 O / ready [0] Selecon list 0x2022:007 general
* Default seng depending on the size. Firmware version 05.00.00.00
Commissioning
Keypad parameter list
