DMS 1.3 EN - 02/2011 L 31

Control technology| System manual

System description

System components

4.1.5 Visualisation with »VisiWinNET®«

To visualise the machine and systems engineering, »VisiWinNET®« is available as a modu-

lar and scalable visualisation system. Here, we distinguish between the engineering sys-

tem and the runtime software.

The L-force Visu runtime software comes installed in the Industrial PC. In combination with

the control technology, it is the »VisiWinNET®« compact CE variant. It runs in parallel to the

other runtime software as for example L-force Logic on the Industrial PC.

4.1.5.1 Development system »VisiWinNET®«

The creation of the visualisation interface require the »VisiWinNET®« engineering system

which has to be installed on an Engineering PC. This is available in two versions:

 »VisiWinNET®« Smart

To create a simple interface, the »VisiWinNET®« Smart is available free of charge as a user-

friendly visualisation system. It can be used as a flexible tool for creating simple applicati-

ons or as service tool. »VisiWinNET®« Smart is provided with an own full-graphics integra-

ted development environment and supports the user by ready-made templates. The

special strength of the system is the option to combine it with »VisiWinNET®« Professio-

nal.

• Features »VisiWinNET®« Smart

– For simple B&B applications

– For applications in the machine-oriented field

 »VisiWinNET®« Professional

The »VisiWinNET®« Professional system is completely implemented in the

Microsoft® Visual Studio .NET integrated development environment and is the basis for

creating visualisation and SCADA applications with high functionality. Ready-made temp-

lates and modules serve to create applications fluently per "drag and drop".

If required, the system permits individual program-related changes on the basis of Visual

Basic .NET and C#. This serves to solve company-specific and complex tasks when the stan-

dard visualisation functions are not sufficient.

• Features »VisiWinNET®« Professional

– For complex B&B applications

– For client/server-based SCADA systems

– For individual and company-related programming

– For connection to databases or other Office programs

– For use of complex report functions
