Product description
Identification
Motor code
3
12
Lenze • BA 33.0006 • 5.1
3.1.1 Motor code
MCA; MCS; MQA
servo motors
Example M C A 21X25 - RS0 B0 - A38R - ST5
S00N
- R0SU
Meaning Type Motor code
Product line M
Type
Compact servo motors (if required, with axial
ventilation)
C
Radially ventilated motor Q
Design
Asynchronous A
Synchronous S
Motor frame size, motor
length, speed
Square dimension 62 mm 06
Square dimension 89 mm 09
Square dimension 102 mm 10
Square dimension 116 mm 12
Square dimension 130 mm 13
Square dimension 142 mm 14
Square dimension 165 mm 17
Square dimension 192 mm 19
Square dimension 200 mm 20
Square dimension 214 mm 21
Square dimension 220 mm 22
Square dimension 260 mm 26
Overall length C...X
Speed in 100 rpm XX
Speed, angle encoder
Resolver p=1
-
RS0
Multiturn absolute value encoder with sin/cos
signals, Hiperface
SKM
Singleturn absolute value encoder with sin/cos
signals, Hiperface
SRS
Multiturn absolute value encoder with sin/cos
signals, Hiperface
SRM
Singleturn absolute value encoder with sin/cos
signals, EnDat
ECN
Multiturn absolute value encoder with sin/cos
signals, EnDat
EQN
Multiturn absolute value encoder with sin/cos
signals, EnDat
EQI
TTL incremental encoder with commutation signals
UVW (IK4096-5V-T, Renco R35i)
C40
Incremental encoder TTL TXX
Incremental HTL encoder HXX
Resolver p=1 for safety function RV0
Singleturn absolute value encoder with sin/cos
signals, Hiperface for safety function
SVS
Multiturn absolute value encoder with sin/cos
signals, Hiperface for safety function
SVM
Incremental encoder for safety function S1S
Sin-Cos IG2048-5V-S incremental encoder S20
No encoder NN0
Brake
Without brake B0
Spring-applied brake 24V DC F1
Spring-applied brake 24V DC, reinforced F2
Spring-applied brake 205V DC F5
Spring-applied brake 205V DC, reinforced F6
Spring-applied brake 230V AC FG
Spring-applied brake 230V AC, reinforced FH
PM brake 24V DC P1
PM brake 24V DC, reinforced P2
PM brake 205V DC P5
PM brake 205V-DC, reinforced P6
