Product description
Identification
Motor code
3
14
Lenze • BA 33.0006 • 5.1
MCM
servo motors
Example M C M 06 B 30 - RS0 B0 A11 ST S00 RU
Meaning Type Motor code
Product line M
Type Compact servo motors (if required,
with axial ventilation)
C
Design Synchronous M
Motor frame size
Square dimension 62 mm 06
Square dimension 89 mm 09
Square dimension 116 mm 12
Motor length
20 B
30 C
40 D
50 E
60 F
70 G
80 H
90 I
100 J
Speed 100 rpm 3000 30
Mains voltage 400 V -
Speed sensor, angle
sensor
Resolver p=2 RS0
Multiturn absolute value encoder with
sin/cos signals, Hiperface
SKM
Brake
Without brake B0
Spring-applied brake 24V DC F1
Design
Standard flange form A/FF with
through hole, cyl. shaft without keyway
A
Standard flange form A/FF with
through hole, cyl. shaft with keyway
B
Shaft
Shaft 11x23 (MCM06) 11
Shaft 14x30 (MCM09) 14
Shaft 19x40 (MCM12) 19
Electrical connection Separate circular connectors for
power/brake, encoder/KTY
ST
Cooling Natural ventilation / without fan S00
Motor protection,
temperature
KTY sensor R
Specification Specification - UL design and CSA
design, approval
U
