About these instructions
This documentation applies to the smd frequency inverter, and contains important technical data and
describes installation, operation, and commissioning.
These instructions are only valid for smd frequency inverters with software rev 20 (see drive
nameplate).
Please read the instructions before commissioning.
© 2004 Lenze AG
No part of this documentation may be copied or made available to third parties without the explicit written approval of
Lenze AG.
All information given in this documentation has been carefully selected and tested for compliance with the hardware and
software described. Nevertheless, discrepancies cannot be ruled out. We do not accept any responsibility nor liability for
damages that may occur. Any necessary corrections will be implemented in subsequent editions.
Scope of delivery Important
• 1
smd inverter (ESMD...)
with EPM installed
(see Section 4.2)
• 1 Operating Instructions
After receipt of the delivery, check immediately whether the items
delivered match the accompanying papers. Lenze does not accept any
liability for deficiencies claimed subsequently.
Claim
• visible transport damage immediately to the forwarder.
• visible deficiencies/incompleteness immediately to your Lenze
representative.
A
Certifications
B
Type
C
Input Ratings
D
Output Ratings
E
Hardware Version
F
Software Version
C0001
(0000000000000000000)
CA B D E F
5D81
LISTED
IND. CONT. EQ.
Made in USA
Inverter
smd
CANopen: Full I/O
Type: ESMD223C4TXA
Id-No: 00000000
INPUT:
3/PE
400 / 480 V
52 / 45 A
50 - 60 HZ
OUTPUT:
3/PE
0 - 400 / 460 V
46 / 40 A
22 KW
0 - 240 HZ
For detailed information
refer to instruction
Manual: SC03
000000000000000000
ESMD223C4TXA000XX ## ##
