Lester LESTRONIC II 17910 - Wiring Diagram

Operating Instructions 6 01537C
This condition can be caused by a charger
problem, a "weak" fuse or circuit breaker
protecting the circuit, or an overloaded circuit. If
the building AC power fuse or circuit breaker
blows, connect the charger to other outlets (on
different circuits) in the building. If the charger
operates properly on other circuits, have a
qualified electrician inspect and test the original
circuit. If the charger causes other fuses or
circuit breakers (in the building) to blow, the
charger should be tested for a problem.
WIRING DIAGRAM
CAPACITOR
TRANSFORMER
FUSE
ASSEMBLY
AMMETER
DIODE HEATSINK ASSEMBLY
ELECTRONIC
TIMER KIT
GREEN
GROUNDED
AC INPUT
WHITE
BLACK
+
-
BATTERIES
TAN
TAN
TAN
BLACK (-)
TAN
TAN
WHITE OR RED (+)
BLACK
BLACK
1
2
3
GREEN
TO
CASE GROUND
4
DC CORDSET
AC
CORDSET
SECONDARY
PRIMARY
ORANGE
BROWN
RED
BLACK
CABLE ASS'Y
CONTROL
1
5
4
3
2
TAN
BUSHING
INPUT
BUSHING
OUTPUT
RELAY
L2120S18
