11. LED INDICATORS
The charger includes three (3) LEDs to indicate charger status and fault information. The functionality of the
LEDs is outlined below. If the charger is equipped with a remote LED assembly, this assembly also includes
three (3) LEDs with identical functionality.
CHARGE STATUS (yellow)
Indicates charge cycle status. See Figure 11-1 for descriptions of the possible states.
CHARGE COMPLETE (green)
Indicates when a charge cycle completes successfully, when an extended Balance/Equalize charge cycle
phase is active, or when a post-charge phase is active. See Figure 11-1 for descriptions of the possible
states.
FAULT (red)
Indicates when a charger or battery fault has occurred. See the FAULTS section.
Charge Status
(Yellow) LED
Charge Complete
(Green) LED
Description
Slow Blink
Off
Bulk/Start charge cycle phase (constant power or
constant current).
Fast Blink
Off
Absorption/Plateau charge cycle phase (constant
voltage). Greater than 80% charged.
Solid On
Off
Finish charge cycle phase (constant current). Not all
charge profiles include a Finish phase.
Off
Fast Blink
Balance/Equalize phase. An extended charge cycle
is occurring because a trigger condition has been
met (cycle count, etc). Not all charge profiles include
a Balance/Equalize phase.
Off
Solid On
Charge cycle complete.
Off
Slow Blink
Charge cycle complete. Post Charge phase
(constant voltage float, etc). Not all charge profiles
include a Post Charge phase.
Figure 11-1: Charger LED States (Non-Fault)
