Mounting
Leuze electronic MLC 520 EX 31
1 Transmitter
2 Receiver
3 UM60 deflecting mirror
Figure 6.10: Arrangement with deflecting mirror for 2-side guarding of a point of operation
1 Transmitter
2 Receiver
3 UMC deflecting mirror column
Figure 6.11: Arrangement with deflecting mirror columns for two-side guarding of a point of operation
2
1
3
2
1
3
