Electrical connection
Leuze electronic MLC 530 61
FG2, fixed blanking can be activated, DoubleScan is pre-set and permanent and there is an option of inte-
grating a contact-based safety circuit.
• Fixed blanking, see chapter 4.7.1 „Fixed blanking“
• Floating blanking (see chapter 4.7.2 „Floating blanking“) as well as the combination of fixed and
floating blanking (see table 7.7)
• SingleScan, DoubleScan can be selected, see chapter 4.5 „Scan mode“
• Integration of contact-based safety circuit possible, see chapter 4.6.1 „Contact-based safety circuit“
• Reduced resolution (reduction by 1 beam) possible, see chapter 4.7.4 „Reduced resolution“
Permanent settings which cannot be changed by control signals:
• Internal start/restart interlock deactivated
Table 7.7: Operating mode 3 pin assignment with both FG1 and FG2 function groups
Teach blanking by opening the bridge between pin 1 and pin 3 with a teach key switch and ap-
plying a voltage of +24 V to pin 1 and a voltage of 0 V to pin 3 (see table 7.5).
Pin FG1: fixed and float-
ing blanking as well
as reduced resolution
and SingleScan
FG2: fixed blanking and
DoubleScan
Teaching the blank-
ing (open bridge,
apply voltage)
Integration of a con-
tact-based safety cir-
cuit in FG1 and FG2
1 (IO1) Bridge to pin 3 (IN3) Bridge to pin 3 (IN3) +24 V
3 (IN3) Bridge to pin 1 (IO1) Bridge to pin 1 (IO1) 0 V
4 (IN4) +24 V 0 V Normal closed con-
tact between supply
voltage or control out-
put and pin
8 (IN8) 0 V +24 V Normal closed con-
tact between protec-
tive field inputs and
device
2 0 V 0 V 0 V 0 V
7 +24 V +24 V +24 V +24 V
5 OSSD1 OSSD1 OSSD1 OSSD1
6 OSSD2 OSSD2 OSSD2 OSSD2
