Hardware Manual
15
Connecting Multiple Cameras
To connect multiple cameras, use a PoE switch.
1) Connect the camera(s) to the PoE switch using Ethernet cables.
2) Connect the PoE switch to a network and an AC power source.
3) Connect a PC to the same network.
Network
AC Power
Source
PoE Switch
Power Cable
Ethernet Cable
Ethernet Cable
(Data)
Cameras
Ethernet Cables
(Data+Power)
Step 3: Access the Camera and Adjust the Focus
After installing the camera, access the camera Live View display (see Accessing Camera on
page 16) and move the lens knob to adjust the camera focus.
