LevelOne FCS-0032 - Installation Procedures; Step 1: Mount the Camera

Hardware Manual
9
Installation Procedures
Step 1: Mount the Camera
1. Mount the Bracket
The bracket can be mounted on a concrete or wooden wall or ceiling. Select the location
where you want to mount the bracket.
When mounting on a concrete wall or ceiling
1. Mark the location of the three screw holes on the wall or ceiling and drill the holes.
2. Insert the supplied plastic washer into each hole.
