Hardware Manual
19
Step 2: Attach the Camera to the Bracket
NOTE: The following images show the mounting bracket attached on the bottom side of the
camera. Same procedures apply when attaching the mounting bracket on the top side.
1. If necessary, insert a memory card into the memory card slot of the camera with the metal
contacts facing down. Push until the card clicks into place. See How to Install / Remove the
Memory Card on page 23 for more information.
2. Slightly loosen the knurled knob.
3. Screw the camera to the bracket.
