Step 3: Connect the Cable
1. If the cable will pass through the hole on the surface, route the network cable through
the hole. If the cable will go along the surface, remove the cable exit tab on the camera
and route the cable along the surface.
Cable Passing Through a Hole on the Surface Cable Going Along the Surface
2. Connect the network cable to the Ethernet port of the camera.
Step 4: Attach the Fixing Bracket
This step is required only for FCS-3053, FCS-3063 camera models with cables going along
the surface. Otherwise, skip this step.
1. Route the cable to pass through the gap on the camera.
or
