Japanese: 15)
F4 Prints out the current hotkey, keyboard operating platform, and language code
settings.
F5 Performs a USB reset.
R [Enter] Resets the Hotkey settings to their default status.
Troubleshooting
Symptom Possible Cause Action
Keyboard / Mouse
needs to be reset.
Unplug the keyboard / mouse from the Console
Keyboard Port, then plug it back in.
Hotkey sequence
input incorrectly.
Resend the Hotkey command - press and
release each key in the sequence individually.
Keyboard
and/or
Mouse Not
Responding
Switch needs to be
reset.
Turn off the computers; wait 5 seconds; turn the
computers back on.
Video
Problems
Resolution and/or
Refresh rate set too
high.
Select a lower resolution and/or bandwidth.
Specifications
Function KVM-0223
Computer Connections 2
Port Selection Hotkey
Keyboard 1 x USB Type A Female (Black)
Video 1 x HDB-15 Female (Blue)
Mouse 1 x USB Type A Female (Black)
Console
Ports
Speaker 1 x Mini Stereo Jack Female (Green)
Keyboard/ Mouse 2 x USB Type A Male (Black)
Video
2 x HDB-15 Male (Blue)
Connectors
KVM
Ports
Speaker 2 x Mini Stereo Plug Male (Green)
LEDs Selected 2 (Green)
Cable
Length
Computers 1.2m
Emulation Keyboard/ Mouse USB
Video 2048 x 1536; DDC2B
Scan Interval 5 Seconds
Operating Temp. 0-50°C
Storage Temp. -20-60°C
Environment
Humidity 0-80% RH, Non-condensing
Housing Plastic
Weight 0.40 kg
Physical
Properties
Dimensions
(L x W x H)
8.1 x 6.3 x 2.35 cm
