LED / Button / Interface
The Device is powered LED will be on when AP is
powered on.
When there are devices normally connected to
port, the port corresponding indicator light will be
on.
Link/Act LED will blink when there is traffic on that
port
The PoE port is used to connect the power.
Power can be provided by a LevelOne PoE
Switch or a 802.3af Poe injector.
The LAN port is used to connect to network
devices, such as a switch.
With the AP powered on, press the Reset button
with a bent paperclip for 5 seconds until the
Link/Act LED goes off. The AP Will restart itself
and reset the device to factory default settings.
