The Device is powered LED will be on when AP is
powered on.
After the AP is powered on and wireless is enabled,
WLAN LED will blink when transmitting/receiving
wireless Data.
The USB port is used to charge external
devices(mobile phone, pads). The output Voltage is
5V 1A.
The Phone port is used to connect a telephone.
The PoE port is used to connect the power.
Power can be provided by a LevelOne PoE
Switch or a 802.3af Poe injector.
The LAN port is used to connect to network
devices, such as a switch.
The RJ11 block is used to connect to a 4-core
telephone cable.
With the AP powered on, press the Reset button
with a bent paperclip for 5 seconds until the
Link/Act LED goes off. The AP Will restart itself
and reset the device to factory default settings.
