2.2 Meter Anatomy
All user connections are made on the circuit board. Connectors are
identied by function and include polarity markers.
Cat. 71D12 Series 7100 Branch Circuit Monitor,
Plastic Enclosure 12 Input, with LCD Display
Cat. 70D48 Series 7000 Embedded Branch Circuit Monitor,
Mounting Plate 48 Input, with LCD Display
Conduit
Connection
Alarm
Ethernet
USB
RS-485
+12V Out
Mounting Hole (6)
Voltage Cover
(transparent)
Voltage
Connector
Pulse Input 1 & 2
CT Inputs
Pulse Input 3 & 4
Serial #
Model #
MAC ID(s)
Expansion
Card (12V)
Serial #
Model #
MAC ID(s)
Voltage Cover
(transparent)
Element ID
Plate Ground
Voltage
Input 1
Voltage
Input 2
Element ID
LCD Display
Navigation
Buttons
Expansion
Card (12V)
Alarm
USB
Ethernet
Pulse Input
+12 VDC
RS-485
Pulse Input
