6
The VerifEye
®
7000 Series and the VerifEye
®
7100 Series meters monitor the voltage,
current, power, energy, and many other electrical parameters on single and three-phase
electrical systems. A VerifEye
®
meter uses direct connections to each phase of the
voltage and current transformers to monitor each phase of the current. Information on
energy use, demand, power factor, line frequency, and more are derived from these
voltage and current inputs.
Each of these meters are not meant to be standalone energy recorders; rather they
are connected as slave devices to a data logger, Remote Terminal Unit (RTU), or
Building Management host network. The VerifEye
®
meter communication interfaces
include Ethernet (LAN), or RS-485 serial. BACnet MS/TP and Modbus RTU are the two
communication protocols that operate over an RS-485 serial network and BACnet IP and
Modbus TCP are supported over Ethernet. A USB port is also provided as the preferred
connection for on-site conguration and can be run concurrently with an RTU.
2.1 Unpacking the Unit
You can order the VerifEye
®
meters with optional product features, which are
identiable on the part number label.
VerifEye
®
Part Numbering Scheme
70D48-000 Series 7000 Embedded Branch Circuit Monitor, Mounting Plate, 48 Input,
with LCD Display
70N48-000 Series 7000 Embedded Branch Circuit Monitor, Mounting Plate, 48 Input,
with no display
71D48-000 Series 7100 Branch Circuit Monitor, Plastic Enclosure, 48 Input, with
LCD Display
70D24-000 Series 7000 Embedded Branch Circuit Monitor, Mounting Plate, 24 Input,
with LCD Display
70N24-000 Series 7000 Embedded Branch Circuit Monitor, Mounting Plate, 24 Input,
with no display
71D24-000 Series 7100 Branch Circuit Monitor, Plastic Enclosure, 24 Input, with
LCD Display
70D12-000 Series 7000 Embedded Branch Circuit Monitor, Mounting Plate, 12 Input,
with LCD Display
70N12-000 Series 7000 Embedded Branch Circuit Monitor, Mounting Plate, 12 Input,
with no display
71D12-000 Series 7100 Branch Circuit Monitor, Plastic Enclosure, 12 Input, with LCD Display
70D03 Series 7000 3-Phase Meter, DIN Rail Mount Plastic Enclosure, with LCD Display
71D03 Series 7100 3-Phase Meter, Wall Mount Plastic Enclosure, with LCD Display
Each VerifEye
®
meter shipment also includes the items below:
• Meter with Options Installed – Serial Number, MAC ID, and FCC ID indicated on
side label
• Pluggable Connectors (voltage, three-position terminals for CT, two-position
terminals for I/O)
• Thumb drive containing VerifEye
®
Power Meter Viewer Utilities Software, Register
List, Manual, Tutorial Videos
• Certicate of Calibration (COC) for each unit
2 INTRODUCTION
WEB VERSION
