Lewmar V1-6 & SPORT Windlass | 15
3.11 V1-6 loading rope/chain
• For safety and performance Lewmar
recommends the use of matched
Lewmar anchor rodes.
1. Remove cover.
2. Pull out control arm.
3. Feed anchor rope/chain into entry
hole. Tie off to suitable strong point.
4. Replace cover. Release control arm
and wrap rope/chain around gypsy.
5. Power load rest of anchor rope/
chain.
• Model V6 chain only
These models have the same loading
procedure as above but do not have
a control arm.
3.11-1 3.11-5
3.11-2
3.11-3 3.11-4
WARNING! Isolate the windlass
using circuit breaker/isolator.
3. Installation
