Lewmar V1-6 & SPORT Windlass | 17
• NOTE: Wireless remote also
available.
• NOTE: Wireless remote can only be
used if a contactor is fi tted. See
wireless remote instructions for
wiring details.
Wireless remote 3 button windlass only Wireless remote 5 button windlass and thruster
68000967 68000968
Model Voltage Cable sizing for length of cable run Circuit breaker Contactor Control Box
Modell
V 0 - 7 m 0 - 23 ft 7 - 15 m 23 - 50 ft 15 - 22 m 50 - 73 ft A
V1/Sport 12 10 mm
2
6 AWG 25 mm
2
4 AWG 35 mm
2
0 AWG 90 A (68000349) 68000318 68000129
V2/Sport 12 10 mm
2
6 AWG 25 mm
2
4 AWG 35 mm
2
0 AWG 90 A (68000349) 68000318 68000129
V2/Sport 24 6 mm
2
10 AWG 6 mm
2
8 AWG 10 mm
2
8 AWG 50 A (68000348) 68000319 68000130
V3/Sport 12 16 mm
2
6 AWG 25 mm
2
2 AWG 35 mm
2
0 AWG 110 A (68000350) 68000318 68000129
V3/Sport 24 10 mm
2
8 AWG 16 mm
2
6 AWG 25 mm
2
4 AWG 90 A (68000349) 68000319 68000130
V4 12 25 mm
2
3 AWG 35 mm
2
0 AWG 50 mm
2
0 AWG 150 A (68000351) 68000320 18000200
V4 24 10 mm
2
8 AWG 16 mm
2
4 AWG 25 mm
2
2 AWG 110 A (68000350) 68000321 18000237
V5 12 25 mm
2
3 AWG 35 mm
2
0 AWG 50 mm
2
0 AWG 150 A (68000359) 68000318 68000128
V5 24 10 mm
2
8 AWG 16 mm
2
4 AWG 25 mm
2
2 AWG 110 A (68000350) 68000318 68000130
V6 24 25 mm
2
2 AWG 35 mm
2
0 AWG 50 mm
2
0 AWG 150 A (68000351) 68000321 18000237
4.3 Control switch installation
Follow the mounting instructions
supplied with the switch.
• NOTE: In a multi station installation
all switches must be wired in a
parallel circuit.
4. Electrical Wiring
4.1 Electric cable selection
Lewmar recommends the installer
source and install cable that meets
the requirements of the standards and
regulations relevant to the installation
and codes of practice.
The cable table gives recommended
cable sizes based on total length
of cable required, from the battery,
following the route of the cables.
DO NOT confuse cable Length
with the length of the vessel!
• Windlass performance is directly
related to cable size and length.
Voltage drop over the complete
wiring run must not exceed 10%.
4.2 Wiring
Plan the installation to suit the
controls and give the operator a full
view of the windlass. The wiring
system should be of the fully insulated
type, which avoids possible electrolytic
corrosion problems. We recommend the
use of type III stranded, tinned copper
wire with copper crimp terminals. Most
modern installations are negative
return (negative ground) but polarity
should be checked.
Overload protection, in the form of the
circuit breaker/fuse supplied, must be
built into the windlass wiring circuit.
• NOTE: The circuit breaker should be
positioned close to the battery in a
dry, readily accessible place.
• The breaker must be manually
reset should an overload occur that
causes it to trip to the off position.
• If you are not sure you understand
these guidelines, seek professional
help. Ensure that the installation
complies with USCG, ABYC, NMMA
or other local regulations.
WARNING!
