16
KIT NO. KIT DESCRIPTION ITEMS INCLUDED QTY.
66000099 Clutch Lever Clutch Lever (1)
66000600 Control Arm Kit 12(1), 24(1), 30(1)
66000601 Gypsy Cap Kit 21(1), 31(1)
66000602 Mounting Kit 5/16” USA 18(1), 26a(1), 33(1), 38(1)
66000603 Gypsy RC 1/4”G4 & 7mm Kit 37a(1), 40(1)
66000604 Gypsy RC 6 mm DIN 766 Kit 37b(1), 40(1)
66000605 Mounting Kit Metric 18(1), 26b(1), 33(1), 38(1)
66000606 Chain Pipe Cover 29(1), 40(2)
66000607 Fall Safe Kit 6(1), 32(1), 34(1), 35(1), 36(1)
66000608 Bearing/Seal Kit 3(1), 4(1), 5(1), 7(1), 13(2), 16(1), 17(1), 19(1)
66000609 Driveshaft Kit 1(3), 8(1), 11(1), 16(1), 20(1), 21(1)
66000610 Motor Kit 6(3), 9(2), 16(1), 25(1), 27(1)
66000611 Gearcase Complete 2(3), 3(1), 13(1), 14(1), 16(1), 17(1), 23(1), 41(3)
66000612 Gear Set 1(3), 8(1), 10(1), 15(1), 16(1), 22(1)
66000613 Compound Gear Assy. 16(1), 22(1)
66000614 1st Compound Gear 15(1), 16(1)
66000615 Magnet & Sensor Kit 39(1)
ITEM DESCRIPTION
1 SS Roller
2 M6 Spring Washer
3 Needle Roller Bearing
4 Roller Clutch
5 Ball Bearing
6 M5 x 12 CSK Socket Screw
7 Internal Circlip
8 External Circlip
9 Black Nylon Cable Tie 200 mm
10 Mainshaft Gear 48 Teeth
11 Mainshaft Spacer
12 Control Arm Torsion Spring
13 Needle Roller Bearing
14 Gearcase
15 1st Compound Gear
16 Gear Case Gasket
17 Needle Roller Bearing
18 Clamping Plate
19 Wiper Seal
20 Mainshaft
21 Drive Washer
22 2nd Compound Gear Assy.
23 Bush 6 x 12
24 Control Arm Shoulder Screw
25 Motor Cover
26a Mounting Studs 5/16” (USA)
26b Mounting Studs Metric M8
27 IP67 Motor, 320 W
28 Baseplate
29 Chainpipe Cover
30 Control Arm
31 Gypsy Drive Cap
32 Fall Safe Pawl
33 Chain Pipe Sleeve
34 Fall Safe Lever
35 Fall Safe Shoulder Screw
36 Fall Safe Spring
37a Gypsy RC 1/4”G4 & 7 mm DIN766
37b Gypsy RC 6 mm DIN 766
38 Basemat
39 Magnet & Sensor Kit
40 M6 x 20 mm SKT HD Cap Screw
41 M6 x 60 mm SHT HD Cap Screw
GB
9.1 Service kits
9.2 Parts list key
