59
DC-2 Digital Controller
Specifications
7
Specifications
S
pecifications
Inputs: Audio: 8 stereo (RCA) pairs
Video: 5 composite (RCA), 5 S-video,
Digital: 8: 5 coaxial (RCA), 3 optical (TosLink),
conforms to IEC-958, S/PDIF standards
Outputs: Audio: 8 outputs: Left, Center, Right, L&R Sides, L&R Rears, Subwoofer (RCA)
Video: 2 composite (RCA), 2 S-video
Audio: A/D Conversion: 24-bit Delta-Sigma
D/A Conversion: 24-bit Delta-Sigma
Frequency Response: 10 Hz – 20 kHz, +0.2dB, -0.3dB, referenced to 1kHz
THD+Noise: Less than 0.005% @ 1kHz,
Dynamic Range: 100dB minimum, 22kHz bandwidth, referenced to
1kHz @ –60dB below maximum output level
Signal-to-Noise Ratio: 100dB minimum, 22kHz bandwidth, referenced to
1kHz at maximum output level
Input Level: 2 Vrms for maximum output
with Input Gain=0 dB); 200mV rms for Dolby level
Input Impedance: 100 kΩ in parallel with 150pF
Output Level: 6Vrms (System Volume = +12dB)
Output Impedance: 100Ω in parallel with 150pF
Video: NTSC M, PAL and SECAM-compatible
Output Level: 1 V peak-to-peak
Impedance: 75Ω
Video Signal-to-Noise Ratio: 70dB
Bandwidth: 10MHz
Power Requirements: 90–250 VAC, 50-60Hz, 35 Watts (universal input);
IEC detachable power cord
Dimensions: 17.3"W x 11.5"D x 3.6"H (440 x 292 x 92mm);
Rack mounted: 19.0"W x 11.5"D x 3.5"H (483 x 292 x 89mm)
Weight: 11.25 lbs. (5.11kg)
Environment: Operating Temperature:32° to 95°F (0° to 35°C)
Storage Temperature.: –22° to 167°F (–30° to 75°C)
Relative Humidity: 95% max without condensation
Remote Control: Hand-held, battery-powered infrared remote control unit, uses 2 AA batteries
Specifications subject to change without notice.
